Project |
Technical Parameters |
|
Table body accuracy level |
0.05 level |
|
Device standard table configuration |
HS-5300 three-phase multi-function standard meter Accuracy level: 0.05 |
|
The output voltage |
3×57.7V/100V/220V/380V; adjustment range: 0-120%, adjustment fineness: 0.01%, can be adjusted in phases; |
|
Output current |
3×1mA-50A (100A optional), adjustment fineness: 0.0001A (minimum); |
|
Output phase |
Range: 0-359.99°; adjustment fineness: 0.01°; |
|
Output frequency |
45Hz-65Hz; Adjustment fineness: 0.01 Hz; |
|
Output waveform distortion |
Voltage and current: ≤0.5%; |
|
Power stability |
≤0.05%; |
|
Load characteristics |
Resistive, inductive, capacitive |
|
Start current output |
1mA (minimum), accuracy: 2%, starting power: accuracy 5%; |
|
Test function |
Basic error test; creep test; start test; standard deviation test; image recognition |
|
Communication test |
RS485 communication test, according to the communication protocol of the tested meter; |
|
Device input power |
3 X 220V/380V (Y)±10%, 50Hz; maximum power consumption: 1500VA (8 tables) |
Dimensions:
|
Integrated |
Gauge |
Dimensions: length × width × height mm |
Split |
Gauge |
Dimensions: length × width × height mm |
|
4 |
?1800×800×1800 |
8 |
?1200×800×1800 |
||
|
8 |
?1800×800×1800 |
Cabinet |
600 (width) × 800 (depth) × 1845 (height) |
?
-->
